PPGL Az120 Ral Color Coated Galvalume Steel Roofing

Thickness	0.12-0.6mm
Width	1000/914/762 (width before corrugation) 930/915/910/905/900/880/875/815/810/790/780/680/670/660/655/650(width after corrugation)Ditch and Peak after corrugation12 Ditches/11 Peak; 11 Ditches/10 Peak; 9 Ditches/ 8 Peak
Length	1000-12000mm
Zinc Coating	AZ30-150g/sqm
Paint Top	15 - 35 Microns
Paint Back	5 - 35 Microns
Coating Color	ALL RAL Cards Color
Coating Type	Top Painted : PVDF / HDP / SMP / PE / PU Primer Painted : Polyurethane / Epoxy / PE Back Painted : Epoxy / Modified Polyester
Weight Per Bundle	2-5 tons

Size List

Effective Width/Full Width(mm)	Feeding Width(mm)	Thickness(mm)
828/935	1000	0.1-0.8
1100-1180	1250	0.1-0.8
950/1040	1200	0.1-0.8
740/800	960	0.1-0.8
760-820	980	0.1-0.8
630/680	750	0.1-0.8
840/890	1000	0.1-0.8
750/820	1000	0.1-0.8
820/840	1000	0.1-0.8
600/650	1000	0.1-0.8
688/750	1000	0.1-0.8
900/940-950	1000	0.1-0.8
820/910	1000	0.1-0.8
880/900-910	1000	0.1-0.8
1025/1100	1200	0.1-0.8

Package	Covered with a layer of plastic film and cardboard, packed onthe wooden pallets,bound with iron belt,loaded in the containers
Monthly Output	10000 tons
Remarks	Insurance is all risks and accept the third party test
Loading Port	Tianjin/Qingdao Port

If you are interested in our products, you can directly contact me for catalog and consultation details, we will reply to you within 24 hours!


